Description
- 2.5 Series front coilovers and rear shocks with remote reservoirs for superior damping and vehicle control along with improved shock cooling
- Adjustable front ride heights from 5-6 of front lift over stock (up to 6″ of lift with only 4″ of crossmember drop)
- Billet rear lower links have replaceable nylon rock sliders to protect the links from trail damage
- Billet rear upper and high clearance lower links improve rear end articulation and allow on-vehicle adjustment for different ride heights and pinion angles using ICON’s double adjuster system
- Front and rear heavy-duty bump stop brackets
- High angle outer tie-roads feature durable, metal on metal greaseable tie rod ends
- Hight clearance front crossmembers and front skid plate, CNC Laser Cut and brake-formed from 1/4-inch steel plate
- ICON engineered custom triple rate rear coil springs provide progressive spring rates for a comfortable ride on-road as well as stability and control during aggressive off-road driving
- ICON Intelligent Control (IIC) uses onboard sensors to monitor G-forces and movement of vehicle chassis along with user defined settings to actively make on-the-fly, near instantaneous compression damping adjustments on CDEV-equipped shocks
- ICON’s Compression Damping Electronic Valve (CDEV) technology allows for in vehicle adjustment of compression damping settings and active adjustment via IIC
- Improved rear sway bar links and mounts, and rear track bar bracket to reduce bind in the rear suspension
- Included sway bar drop brackets reduce bind in OE sway bar links
- Maintains factory track width
- On-vehicle adjustable billet rear track bar properly centers rear axle while also improve rear suspension performance
- Optimized design to fit 37″ tires with full articulation (larger tires may fit but fender trimming and modifications will be required)
- Optimized suspension geometry nearly eliminates the bump steer found in stock Tundras
- Patented Delta Joint Pro (U.S. Pat. 10,731,700) provides improved durability and serviceability with 90 degrees of total articulation
- Single piece high-strength ductile iron steering knuckles with built-in 4″ drop
- System allows for up to 40% increase in front wheel travel over stock without overstressing OE components
- Tubular UCAs with Delta Joint Pro for added strength, durability, and caster correction for improved drivability
- OEM Wheels & Tires Fitment: No
- APPLICATION NOTE #141: Tundra/Sequoia equipped with automatic leveling headlights or Load-Leveling Rear Height Control Air Suspension, part # 55153 is also required
- APPLICATION NOTE #142: Not compatible with vehicles equipped with Load-Leveling Rear Height Control Air Suspension.
- APPLICATION NOTE #153: Not compatible with Adaptive Variable Suspension (AVS) equipped vehicles
- APPLICATION NOTE #155: Requires recalibration of Advanced Driver Assistance Systems (ADAS) after install
- APPLICATION NOTE #198: An iOS operated device is required to run ICON Intelligent Control app
- APPLICATION NOTE #55: Shocks are fully serviceable. Lift heights indicated are for a stock equipped vehicle.
- APPLICATION NOTE #85: Advertised lift height ranges are for a stock equipped vehicle. Increasing weight of vehicle due to accessories will alter lift range.
- Recommended Aftermarket Tires: 37″ x 12.50″ (Larger tires may fit but fender trimming and modifications will be required.)
- Recommended Aftermarket Wheels: ICON Alloys – 20×9″ w/ 5.625” Backspace / 16mm Offset
- TECH NOTE: Most Tundra sub-models equipped with i-Force gasoline engine will have front lift height range of 5-6″ over stock.
- TECH NOTE: Most Tundra sub-models equipped with i-Force MAX hybrid engine will have front lift height range of 4.5-5.5″ over stock.
- TECH NOTE: Provides 3″ of rear lift on a Tundra equipped with TRD Off-Road or TRD Sport suspension packages and TRD Pro. A Tundra without TRD Off-Road or TRD Sport suspension packages will net 3.5″ of rear lift.
- TECH NOTE: Requires minimum of 20″ diameter wheels
- TECH NOTE: Tundra SR5 with TRD Sport package will have front lift height range of 6-7″ over stock.
- TECH NOTE: Tundra TRD Pro will have front lift height range of 3.25-4.25″ over stock.
